Kia Forte: General Information / Basic Service Symbols

Kia Forte 2019-2025 (BD) Service Manual / General Information / Basic Service Symbols

General information
Basic Service Symbols

There are five primary symbols used to complement illustrations. These symbols indicate the part to apply such materials during service.

Symbol
Meaning

Do not reuse the part. Replace a new one.

Apply engine oil or transmission oil to the part.

Apply automatic transmission fluid (ATF) to the part.

Apply grease to the part.

Apply sealant to the part.
